EXTRA-DUTY PLASTIC IN-USE WEATHERPROOF COVER, SINGLE-GANG, VRT/HRZ, 2.75″ CLEAR

Plastic In-Use Weatherproof Covers are extra-duty rated and easy to install. Covers come with a gasket, mounting screws, base, cover assembly and inserts to meet the needs of a variety of applications.

Features & Applications

Features

• Complies with 2017 NEC Article 406.9 (B)(1) for wet locations and extra-duty applications
• Exceeds CEC Article 26-702
• UL Certified for Type 3R outdoor enclosures
• Meets requirements for cold impact testing: -60° F (-51° C)
• Heavy-duty UV stabilized polycarbonate cover, mounting base, and inserts
• 1⁄8″ (3 mm) thick, neoprene gasket with slits for mounting screws
• Lockable hasp: All models accept up to 1⁄4″ (6 mm) dia shank
• Impact rated: 12 lbf. impact test to ensure cover remains intact
• Reinforced hinge pin designed to exceed 40 lbf. hinge hang/stress test
• Warranty: 1-year limited
• NEW Faster Installation, Pre-Set for GFCI, No insert required
• Two inserts provided with all models that allow each model to meet multiple installations (up to 16 configurations)
• Max cord size: (2) #14 AWG  or (1) #12 AWG

Applications

• Industrial
• Commercial
• Manufacturing
• Residential
• Agricultural
• Signage
• Athletic Fields
